Introducation:

Coilovers and shocks are parts of the suspension system on automobiles. The major difference between coilovers and standard shocks is that coilovers afford drivers much more control over a vehicle's suspension system.

Application

For Mazda RX-7/Mazda Savanna RX-7 second generation FC3S 1985–1992

2 door coupe/2 door convertible

Specification

- Top mount: Front camber plate；rear pillow ball

- Damping: not available

- Spring rate Front: 10 kg/mm (560 lbs/in)

- Spring rate Rear: 8 kg/mm (448 lbs/in)​

- Adjustable height: lowering 1-3 inch

- Shock type: Twin tube

- Spring Preload: 7-10 mm

- Color: gold body with black springs

Features

1. Lowered height adjustment from 1" - 3" which allow lower center of gravity and also add a more aggressive stance.

2.Camber plate top mounts help to eliminate the need for a separate camber kit.

3.Twin-Tube structure allows sufficient stroke within the shock absorber.

4.Complete Suspension Kit of 4 Shock Absorbers 4 Springs for an easy installation.

5.Separate height adjustment does not affect damper stroke and height can be adjusted with coilovers installed on the vehicle.

6.High Tensile performance spring - STRESS TESTED OVER 600,000 times while the spring distortion is less than 0.04%. Plus the special surface treatment improves the durability and performance.

7.Most pieces in our coilover systems, including mounts, collars and spring perches, are designed from 6061-T6 Billet Aluminum resulting in lightweight, durable and rust resistant components.

8.Steel shock bodies with special surface treatment to improve the durability.

9. Full rebuildable

Package included

- 2 Front + 2 Rear Full coilovers

- A pair of wrenches for height adjustment

Code: MXR02FXSY

Notice：California Prop 65 Warning
